Medicine Curing Spray Dryer Orice 2L Spray Dryer Milk Lab Hot Air Hammer

1.0 Sets
MOQ
Medicine Curing Spray Dryer Orice 2L Spray Dryer Milk Lab Hot Air Hammer
Características Galeria Descrição de produto Peça umas citações
Características
Especificações
Type: Spray Drying Equipment
Application: Medicine Processing, Chemicals Processing, Food Processing
Condition: New
Voltage: 220V
Power: 5KW
Dimension(L*W*H): 1050mm*1000mm *1650mm
Key Selling Points: easy to iperate
Warranty: 1 Year
Weight (KG): 210
Applicable Industries: drying machine
Showroom Location: None
Marketing Type: Ordinary Product
Machinery Test Report: Not Available
Video outgoing-inspection: Not Available
Warranty of core components: 1 Year
Core Components: Pump, PLC, Engine
Evaporation Capacity(kg/h): 1.5
Heating Method: Electric Heating
Material: SUS304, SUS316
Name: Lab Inert Loop Spray Dryer
Model: YC-015A
Capacity: 1500ml/h
Body Material: SUS 304 Stainless Steel
Nozzle materil: SUS 316 Stainless Steel
Gas type: N2 ( for organic solvent)or compressor air ( for aqueous )
Max inlet temperature: 200 degrees
Jet Size: 0.7mm as standard(0.5mm, 1.0mm , 1.5mm , 2.0mm is optional
nozzle type: two fluid nozzle
operate mode: manual or automatic
After-sales Service Provided: Online support
After Warranty Service: Online support
Local Service Location: None
Certificação: CE Certificate
Informação básica
Certificação: CE Certificate
Model Number: YC-015A
Condições de Pagamento e Envio
Packaging Details: tri-ply wood with standard spray drying machine
Supply Ability: 100 Set/Sets per Year spray dying machine
Descrição de produto
Company Profile
Shanghai Pilotech Instrument & equipment Co.ltd , starting from 2005 year . With many years of development , we have exported to more than 45 countires . In our demestic country , there are more than 85% of universities have bought our lab spray dryers for their experiment . We have a professional team , high efficiency work ability . We are well oriented to the customers ' needs . We manufacture the full types of the lab spray dryers , such as high-temperature spray dryer , low-temperature spray dryer , vacuum spray dryer , inert loop spray dryer , spray freeze dryer . If you are interested , please consult us !

Contact person : Sabrina Zhang
Email : Sabrina@shpilotech.com
Tel : +86 15872402951
Product Description
Power
5KW
voltage
220V, 50~60HZ
Mini. outlet temperature
40 degrees
capacity
1500ml/h
application
spray drying for organic solvent or aqueous
temperature precious
±1 degrees
nozzle jet
0.7mm( 0.5mm , 1.0mm , 1.5mm , 2.0mm is optional)
particle size
1~25micron
deblocking
automatic
Inert temperature ( for organic solvent )
Yes
Specification

LCD touch screen to operate the whole process

Oil free air compressor to compressor the air

Two fluid nozzle It is made of SUS 316 stainless steel

Nitrogen circulation system

Clamp to secure the parts

Application and outputs
Spray drying for organic solvent
The machine is equipped with the inert loop system . Nitrogen can be recycled using . Nitrogen is safe in contact with organic solvents as an inert gas .
Spray drying for aqueous
The machine also can work for water solution . Such as milk , egg powder , flavours and fragrances , etc .
Relative products
click the picture to find this machine !!!

500ml/h lab inert loop spray dryer

2L/h lab spray dryer

vauum low-temperature spray dryer

FAQ
Q1 . Which kind of products do you have ?
A: Our main products are: mini spray dryer , mini UHT sterilizer , lab multi-functional extracting tank , laboratory Inert Loop
spray dryer , laboratory low-temperature spray dryer (vacuum spray dryer) , laboratory spray freeze dryer , laboratory spray
granulator (spray drying & spray granulating all-in-one) as well as small and pilot composite production line for drinks , milk , yogurt and powder .

Q2. Do all the products have operating interface and operating manual in English ?
A:Y es , all our equipment provide operation interface in English , and if necessary, we can also provide the user's native
language , and all products are available in English operating instructions ; if necessary , we can also provide the user's
desired language version . In addition , there are are operating videos for our products for the convenience of customers to use .

Q3. Do youhave E-catalogue ?
A: Yes , you can send your inquiry to our email , we will send it to you ASAP .

Q4. How about your delivery time ?
A: Generally , it will take 30 to 60 days after receiving your advance payment . The specific delivery time depends on the items and the quantity of your order .

Q5. How is the sales service of company's products ?
A: We offer one-year warranty for all the products , and for products within the warranty period , we provide free services for all non-human damages . After the warranty expires , we will only pay the cost .

Q6. How is the stability and durability of the company's products ?
A: The company has been established for 10 years, and 90 percent of products have been adopted in Chinese colleges and universities . The first produced products have still used by customers currently, and the products are very durable. In China , before the purchase of equipment , many teachers in the university will carefully listen to the views of colleagues on usage. Pilotech Equipment has good performance and stability and achieved a good reputation, and the purchases of numerous new customers are recommended by old customers .

Q7. Do you test all your goods before delivery ?
A: Yes , we have 100% test before delivery .

Q8: How do you make our business long-term and good relationship ?
A: 1. We keep good quality and competitive price to ensure our customers benefit ; 2. We respect every customer
as our friend and we sincerely do business and make friends with them , no matter where they come from .

Q9:How can I track the whole shipping process ?
A: We will send you a BL tracking number.you can track the whole shipping process on the website .
